EZN004

Fixing mode

Din-Rail

Switch mode

change-over contact, usable as NC or NO

Rated operational voltage Ue

12 / 230 V

Frequency

50/60 Hz

Depth of installed product

58 mm

Height of installed product

85 mm

Width of installed product

17.5 mm

Power consumed

15 VA

Power consumption (operation)

15 VA

Total power loss under IN

2 W

Power dissipation per coil

0.5 W

Max. power with incandescent lamps

450 W

Mounting type

din-Rail

Connection cross-sect. flexible conductor

1 / 6mm²

Connection cross-sect. rigid cable

1,5 / 10mm²

Type of connection

with screw terminals

Number of contacts

1

Type of contacts

1 changeover

Protection index IP

IP40

Operating temperature

-10…50 °C
